Pukas x Matt Biolos // The Link
Pukas The Link top
Pukas The Link rocker
Pukas The Link bottom
Words by Matt Biolos (USA)
“After almost 20 years of traveling the Basque Country, and shaping at PUKAS, we finally made our link official and have designed this collaboration model…. The Link.
We thought it would be fun to make this link official and do a special little project…a special board. Specifically for the small punchy beach breaks in this area. Super fun and skatey, but high performance as well. Not a cruiser, or flat glider, but a board with some rocker and some concave, a board that a good surfer can throw around and up into the lip and surf kind of radical, but in a small, fun, beach break kind of way.
From the start I have always sorta been known for pushing the idea of wider shorter boards, but always trying to do it with performance in mind, not just fashion or retro”.
Pukas x Matt Bilos // #CarbonWrap Technology
We are building The LINK in two techs. First, we are launching it with patented “Carbon Wrap” Technology. Stringer-less EPS with a Carbon Fibre frame that “wraps” The rails in a strategic point, creating a lively and electric feeling flex, engineered for maximum performance in small surf. In addition to the Carbon Wrap, we are building.
The Link in the tried and true, proven performance of PU/PE construction.
Pukas The Link #CarbonWrap top
Pukas The Link #CarbonWrap rocker
Pukas The Link #CarbonWrap bottom
#CarbonWrap Technology // What is it?
CARBON WRAP™ Is a patented surfboard technology, structurally engineered for optimum flex and performance. Originally created by Gold Coast surfboard manufacturer, Dan MacDonald, to be light weight without sacrificing strength and provide #nextlevel performance.
Carbon Wrap eliminates the standard wooden stringer, alters traditional flex principles and re-envisions the way a surfboard’s flex patterns are created and controlled. Ultra-light, EPS cores are “wrapped” in an exoskeleton of strategically positioned, carbon fiber bands. Aligned together at the nose, they gradually curve outward towards the rails. The curve creates and controls a unique torsional flex that livens up as it nears the tail, just in front of the fins.
The carbon then “wraps” from the bottom, around the rails and onto the deck. This unique method creates Carbon Wrap’s lively flex that loads and releases…resulting in nextlevel speed and drive. Running along the rails, on the deck, the carbon acts as a rear foot power point, (increasing drive and control) and a patch to minimize pressure denting.
Using optically brightened epoxy resin, the boards are encased with a proprietary composite of fiberglass and our exclusive carbon deck inlay, which is strategically positioned to add fast re-flex memory under the surfer’s stance and allow subtle, natural deck caving around the arch of the front foot. By tapering the carbon into long, pointed ends, forward and aft, the flex blends out naturally towards the nose and tail.
A full layer of 45degree “X-Glass”, encases the deck. The X-Glass’s flat, bi-axel weave dramatically adds strength without rigidity, or excess weight and allows the board to maintain flex while alleviating crease points created by standard, 90degree fiberglass. The 45degree weave radiates foot pressure outward, directly connecting the foot to a longer section of the rail, adding greater edge control.
CARBON WRAP TECHNOLOGY: Lightweight, without sacrificing strength. Increases drive and provides and unique and lightning fast re-flex effect, propelling your surfing into the #nextlevel of performance. For more videos and info, visit the CarbonWrap Website.
Pukas x Matt Biolos // The Link Size Chart
When sized properly, with the right amount of volume, it could be anything from a 5’2 rip stick, for a young ripper to throw airs and blow the tail….
On up to 40 liters of Domestic high perfor- mance carving and snapping to keep the middle aged guy, father with kids out there having fun…..instead of giving up and riding an oversized boat or a flat rocker pi
|5’0”||17 3/4||2 1/8||20,60|
|5’2”||18 1/8||2 3/16||22,30|
|5’3”||18 3/8||2 3/16||23|
|5’4”||18 5/8||2 1/4||24,50|
|5’5”||18 7/8||2 1/4||25,6|
|5’6”||19 1/8||2 5/16||27|
|5’7”||19 3/8||2 3/8||28|
|5’8”||19 5/8||2 3/8||29,10|
|5’9”||19 7/8||2 3/8||29,99|
|5’10”||20 1/4||2 1/2||32,50|
|5’11”||20 3/8||2 1/2||33,25|
|6’0”||20 1/2||2 9/16||35|
|6’1”||20 3/4||2 5/8||36,5|
|6’3”||21 1/4||2 11/16||39,75|
|6’4”||21 1/2||2 3/4||41,5|
VIDEO. Joan Duru in Guadalupe with “The Link”.
Una foto publicada por Aritz Aranburu (@aritz_aranburu) el 17 de Nov de 2015 a la(s) 11:36 PST
